EtherCAT Evaluation Environment Introduction
EtherCAT Development & Evaluation Environment
We offer our original EtherCAT evaluation boards that allow you to start evaluating EtherCAT immediately. They support both master and slave evaluation and are ideal for initial operation checks, protocol learning, and PoC (Proof of Concept) in the early stages of development.
We provide evaluation environment for R&D and evaluation of EtherCAT. N-EMB-120 + N-EMB510 can be operated as EtherCAT slave set by installing the hardware master on N-EMB-110 (possible with N-EMB-100 too) We also sell R&D licenses for hardware masters.
Environment explanation
Product description video
Products for Master
| Model | Specification | Details |
|---|---|---|
| N-EMB-100 | Altera Cyclone V SoC | Product Information |
| N-EMB-110 | Altera Cyclone V SoC | Product Information |
| N-EMB-800 | Master IP | Product Information |
| N-EMB-115 | AMD UltraScale+ MPSoC | Coming Soon |
Products for Slave
| Model | Specification | Details |
|---|---|---|
| N-EMB-120 | Altera MAX10 | Product Information |
| N-EMB-130 | Renesas R-IN32-M3-EC | Product Information |
| N-EMB-140 | Texas Instruments AMIC120 | Product Information |
Optional Products
| Model | Specification | Details |
|---|---|---|
| N-EMB-150 | Step Technica CUnet GW | Product Information |
| N-EMB-500-A | Altera MAX10 IO Expansion | Product Information |
| N-EMB-500-B | Altera MAX10 IO Expansion | Product Information |
| N-EMB-510 | Expansion IO for N-EMB-120 | Product Information |
| N-EMB-520 | Motherboard | Coming Soon |
| N-EMB-530 | Motherboard | Coming Soon |
Basic
This video explains the entire process from board setup to sample operation and basic I/O communication.
Advanced
This video introduces how to create more practical applications based on the samples.
FAQ
What is the evaluation environment for?
It is ideal for those who want to start learning EtherCAT, conduct a PoC (Proof of Concept), or perform an initial evaluation of EtherCAT slave development. You can experience EtherCAT operation immediately without complex environment setup.
What is included in the evaluation environment?
The contents vary depending on the product, so please check the product information page for each product.
How can I purchase the evaluation environment and what is the delivery
time?
You can purchase from the store page, but we also offer consultations regarding implementation, so please feel free to contact us.
